DSE’s Rugged Display Used in Winning Model of the US Marines Amphibious Vehicle Competition

In a competition by the US Marines, engineers and manufacturers participated in developing a new prototype for Assault Amphibious Vehicles, or AAVs. BAE Systems’ model won against three other manufacturers, resulting in a contract worth $103.7 million for the Engineering, Manufacturing and Development (EMD) phase of the Amphibious Combat Vehicle (ACV) 1.1 program.Digital Systems Engineering is proud to be BAE’s rugged display of choice for the winning model.DSE was chosen for their ability to modify an existing COTS (commercially available off the shelf) product quickly and cost effectively. The standard MSM212VR product was redesigned to incorporate nickel-zinc coated connectors in place of cadmium plated versions. Additionally, DSE-designed and manufactured a custom video distribution product (VH3) without impacting the program schedule.

About the Amphibious Vehicle

Assault Amphibious Vehicles (AAVs), also referred to as "Amtracks,” function as land-to-water vehicles. Fully armored, these vehicles transport marines and cargo in the most hostile territories.BAE designed an eight-wheeled vehicle, more quiet and comfortable than the previous AAV models that were fully tracked. Additionally, air conditioning and better ventilation relieves nausea previously caused by hot exhaust.The amphibious vehicle delivers substantial capability improvements that not only satisfy the Marine Corps’ current needs, but also meets any future goals and potential challenges.With exceptional ground mobility and protection, the ACV solution:
  • Has suspended interior seat structure for 13 embarked Marines
  • Blast mitigating positions for a crew of three
  • Improved survivability and force protection over currently fielded systems
  • Is equipped with a new 6-cylinder and 700HP power pack, providing a significant power increase
  • Weighs 63,000 pounds and has a payload capacity of 6,000 pounds
  • Can reach speeds of 65 mph on paved roads, 6 knots in the open ocean
  • Has a range of 350 miles or 10 nautical miles at sea followed by 200 miles on land
Feedback from vehicle operators guided the final design of the driver's instrument panel and controls that include push-button automation with a digital architecture.

About BAE Systems

BAE Systems provide some of the world’s most advanced, technology-led defense, aerospace and security solutions. BAE Systems develop, engineer, manufacture and support products and systems to deliver military capability, protect national security and people and keep critical information and infrastructure secure. With over 70 years of experience in designing and building amphibious vehicles BAE Systems is a leading provider of combat vehicles.BAE hand-picked DSE’s rugged displays to maintain their high standard of technology, durability and efficiency in the vehicle prototype.

Digital Systems Engineering

Digital Systems Engineering (DSE) offers custom design, engineering and manufacturing of rugged mobile mil spec and industrial flat-panel LCD displays and computers for multiple markets—primarily the military, security and industrial.Since 1995, as a privately held U.S.-owned small business (FAR 19.102), DSE has achieved a worldwide reputation for excellence in the design and manufacture of leading edge, technology driven display and computer products.DSE is proud to be a part of BAE’s winning model of the US Marines’ Amphibious Vehicle competition.
